You can save a copy of the project visualization purposes: in the copy, you use Break Link to embed all the hotlinks of a module. The Break Link function can be helpful if, for example, a project is nearing completion and you want to create a few internal renderings. Note: The Break command is not available for nested modules. Note: To break any single placed Hotlink, select the Hotlink and use the Break Hotlink (Embed Elements) from Hotlink Settings. This command is not effective on Hotlinks which are on a locked layer. The elements will be regular editable ARCHICAD elements, grouped together but no longer part of a module and no longer linked to any other source file. Select one to change the module.Ĭheck this box to break all the Hotlinks of this module and embed their elements into the host project. The appearing Select Hotlink Module dialog lists the available Hotlink Modules of this project. To replace the selected module with a different one, click Change Module. Note that selecting a module in this list highlights the name of its source file in the “Hotlink Sources” list below. You can also hover the cursor over a listed Module to see information about it, including the module’s location in the host file. –For Rhino-based Modules: import options for this module (e.g. –For IFC-based Modules: the Template and Translator files, and the template file’s location the linked story (or stories) of this module.the number of placed Hotlinks from this module.The list is hierarchical, indicating any nested modules at a lower level in the tree structure.

The “Hotlink Modules” list (in the top half of the dialog box) shows the hierarchy of modules hotlinked into the current project. the context menu of any Hotlink in the project, under Hotlink Module.
